Agility and control
Updated flat-bar frame geometry puts the rider in a position that balances efficiency with stability, and disc brakes give you added control on rugged roads or dirt.
Smooth-riding comfort
The D-Fuse seatpost and suspension fork absorb road shocks and vibrations, and EasyRide Tubeless tires let you run lower pressure for a smoother ride quality and a reduced risk of flats.
Integrated rack mounts
Compatible with rear racks, allowing easy cargo capacity for daily trips or longer treks.
Seat Tube Angle: 73.0°
Top Tube Length (mm): 610
Head Tube Length (mm): 145
Head Tube Angle : 70.5°
Fork Rake (mm): 42
Trail (mm): 85
Wheelbase (mm): 1109
Chain Stay Length (mm): 450
Bottom Bracket Drop (mm) : 62
Stack (mm): 634
Reach (mm): 416
Stand Over Height (mm): 788
Handlebar Width (mm): 680
Stem Length (mm): 90
Crank Length (mm): 175
Size: L
Colour: Stealth Chrome
Frame: ALUXX-grade aluminum, disc
Fork: SR Suntour NEX 700C, 63mm
Shock: N/A
Handlebar: Giant Sport XC, 31.8mm S:64cm, M:68cm, L:68cm, XL:68cm
Grips: ErgoContact
Stem: Giant Contact, 8-degree S:70mm, M:80mm, L:90mm, XL:100mm
Seatpost: Giant D-Fuse, alloy, 350mm
Saddle: ErgoContact
Pedals: platform
Shifters: Shimano Altus, 2x8
Front Derailleur: Shimano Tourney FD-TY606
Rear Derailleur: Shimano Altus RD-M310
Brakes: Tektro TKD-143 hydraulic [F]160mm, [R]160mm rotors
Brake Levers: Tektro TKD-173
Cassette: Shimano CS-HG31, 11x34
Chain: KMC Z7
Crankset: forged alloy, 30/46 S:170mm, M:170mm, L:175mm, XL:175mm
Bottom Bracket: threaded
Rims: Giant double wall aluminum
Hubs: alloy, 32h
Spokes: stainless, 14g
Tyres: Giant CrossCut, anti-puncture, 700x42c
Extras: 53mm max tire size
Compatibility: Compatible with Direct Mount KSA 18mm Kickstand
Max Tyre Clearance: 53mm
| GTIN | 4711291209107 |
|---|
